Fox FV721 Modelling Challenge (Step 6: Shaft tip)

This step models the tip of the front and rear axles. Modeling itself is simple but complicated when modeling the outer section where it looks like a rib with hexagonal holes for bolts. For one model it is a circle of 32 vertices. and added to another circle of holes 8. To simulate nervadua we made a first extrusion. and then add the circle of 8 in the section where it belongs. This also was extruded in the same magnitude and thus delineates the rib and then extruding continuous redimencionado the aguguero as needed. Once this is eiminan faces that left over and join the mesh. To make the rest of the agugueros (seven in total). Faces are removed which are not needed and the turning tool are copied to eight times the hole through 360 °. For bolts exaginales adds a 6-sided polygon. All edges are selected and divided 2 vecez each totaling 18 vertices. Is extruded and then modified to describe the way. To achieve sharp edges is used as the bevel tool shown in the image. En este pas...
